Blackmagic Design Mini Converter Analog to SDI

Mini Converter Analog to SDI is perfect for converting from analog video in HD/SD component, NTSC, PAL or S-Video to SDI video with the choice to embed SDI audio from balanced AES/EBU or analog audio inputs. Now you can convert analog devices such as Betacam SP, VHS, Set top box's and HDV cameras to SDI video.

Connections
SDI Video Outputs
2 x SDI Video Outputs.

Analog Video Inputs
NTSC, PAL, S‑Video and Component SD/HD input.

Analog Audio Inputs
2 channels of balanced analog audio.

Digital Audio Inputs
2 channels of balanced AES/EBU audio.

Multi Rate Support
Auto detection of SD or HD.

Updates and Configuration
Via USB 2.0 high speed. (480 Mb/s)

Reclocking
Yes

Mini Converter Analog to SDI
Standards
SD Video Standards
525i59.94 NTSC, 625i50 PAL

HD Video Standards
720p50, 720p59.94, 720p60
1080i50, 1080i59.94, 1080i60

SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, ITU‑R BT.656 and ITU‑R BT.601.

SDI Video Sampling
4:2:2

SDI Audio Sampling
Television standard sample rate of 48 kHz and 24 bit.

SDI Color Precision
4:2:2

SDI Color Space
YUV

SDI Auto Switching
Automatically follows format of analog input.

Analog Color Space
YUV

Analog Color Precision
4:2:2
