Camera Features
Effective Sensor Size
35.64mm x 23.32mm (Large Format)

Pixel Pitch
2.9 microns

Lens Mount
URSA Cine lockable EF mount. Interchangeable with optional URSA Cine PL mount.

Lens Control
Lens control of compatible EF lenses. Lens data from compatible PL lenses and control of some PL lenses.

Dynamic Range
16 Stops

Shooting Formats
12,288 x 8040 (12K 3:2 open gate)
12,288 x 6912 (12K 16:9)
12,288 x 6480 (12K 17:9)
12,288 x 5112 (12K 2.4:1)
9648 x 8040 (12K 6:5)

9408 x 6264 (9K 3:2)
8688 x 4896 (9K 16:9)
9312 x 4896 (9K 17:9)
9312 x 3864 (9K 2.4:1)
7680 x 6408 (9K 6:5)

8192 x 5360 (8K 3:2 open gate)
8192 x 4608 (8K 16:9)
8192 x 4320 (8K 17:9)
8192 x 3408 (8K 2.4:1)
6432 x 5360 (8K 6:5)

4096 x 2680 (4K 3:2 open gate)
4096 x 2304 (4K 16:9)
4096 x 2160 (4K 17:9)
4096 x 1704 (4K 2.4:1)
3216 x 2680 (4K 6:5)

Frame Rates
Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 fps supported. Maximum sensor frame rate dependent on resolution selected.

High Speed Frame Rates
12K 3:2 open gate up to 80 fps

12K 17:9 up to 100 fps

12K 2.4:1 up to 120 fps

9K 3:2 Super 35 up to 100 fps

8K / 4K 3:2 open gate up to 144 fps

8K / 4K 2.4:1 up to 224 fps

Built in ND Filters
Button activated ND filters with clear, 2-stop, 4-stop and 6-stop IR ND filters.

Focus
Focus button turns on peaking, auto focus available using compatible lenses.

Iris Control
Iris wheel and touchscreen slider for manual iris adjustment on electronically controllable lenses, iris button for instant auto iris settings on compatible lenses so no pixel is clipped in film mode. Scene average auto exposure in video mode.

Screens
2 x Monitoring Screens

1 x Camera Status Screen

Monitoring Screen Dimensions
5 inch.

Monitoring Screen Resolution
1920px x 1080px

Monitoring Screen Brightness
1500 nits.

Monitoring Screen Type
LCD capacitive touchscreen

Metadata Support
Automatically populated lens data from compatible EF lenses. Automatic recording of camera settings and slate data such as project, scene number, take and special notes.

Controls
Touchscreen menus on 5 inch screen. Push buttons for other controls. 7 assignable shortcut keys plus 6 assignable viewfinder shortcut keys on optional URSA Cine EVF.

Timecode Clock
Highly accurate timecode clock. Less than 1 frame drift every 8 hours.

Connections
Total Video Outputs
2

SDI Rates
1.5G, 3G, 6G, 12G.

Analog Audio Inputs
2 x XLR analog switchable between mic, line and AES audio. Phantom power support.

Analog Audio Outputs
1 x 3.5mm headphone jack

Reference Inputs
Tri-Sync/Black Burst and Timecode.

Viewfinder
1 x Viewfinder USB-C with video, power, camera control data and locking connector. Works with URSA Cine EVF and PYXIS Monitor.

USB-C Monitor Outputs
2 x USB-C side monitor ports support URSA Cine EVF, PYXIS Monitor or DisplayPort monitors.

Accessories
1 x 7-pin Lemo ‘EXT' for power out, serial communication, and run/stop.

1 x 3-pin Fischer ‘RS' for power out and run/stop.

Computer Interface
2 x USB-C side expansion ports for camera accessories.

Software updates using side USB‑C closer to rear.

Ethernet
1 x 10Gb/s RJ‑45 connector supporting 10/100/1000/10G BASE-T for SMB file sharing, Web Media Management, Blackmagic Cloud uploads, camera control and streaming.
