Connections
Total Video Inputs
8

Total Outputs
6

Total Aux Outputs
4

Total Audio Inputs
2 x 3.5mm stereo mini jack.

Total Audio Outputs
1 x 3.5mm stereo mini jack.

Timecode Connection
None

SDI Video Inputs
8 x 3G-SDI, 10-bit HD switchable.

2 channel embedded audio.

Video Input Re-Sync
On all 8 SDI inputs.

Frame Rate and Format Converters
On all 8 SDI inputs.

SDI Program Outputs
4

Ethernet
Ethernet supports 10/100/1000 BaseT for live streaming, software control, software updates and direct or network panel connection.

Computer Interface
2 x USB Type-C 3.1 Gen 1 for external drive recording, webcam out, software control, software updates and panel connection.

ATEM SDI Extreme ISO
Standards
HD Video Input Standards
720p50, 720p59.94, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
1080i50, 1080i59.94, 1080i60
HD Video Output Standards
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
Video Streaming Standards
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
Ultra HD Video Standards
None

Video Sampling
4:2:2 YUV

Color Precision
10-bit

Color Space
Rec 709

Colorspace Conversion
Hardware based real time.

Product Specifics
Upstream Keyers
4

Downstream Keyers
2

Advanced Chroma Keyers
Up to 4

Linear/Luma Keyers
Up to 4

Transition Keyer
DVE only.

Total Number of Layers
9

Pattern Generators
5

Color Generators
2

DVE With Borders and Drop Shadow
2

Interface
Minimum monitor resolution of 1366 x 768.

Audio
Audio Mixer
11 input x 2 channel mixer.

Selectable On/Off/Audio-Follow-Video per channel plus separate gain control per channel.

Level and Peak metering. Plus new Fairlight audio enhancements: Compressor, Gate, Limiter, 6 bands of parametric EQ. Master gain control.

Analog Input
Unbalanced stereo

Analog Input Delay
Up to 8 frames

Input Impedance
1.8k

Max Input Level
+6dBV

Mic Plug In Power
Available on both 3.5mm mini jack connections.

Streaming
Direct Streaming
ATEM SDI Extreme ISO supports direct live streaming using Real Time Messaging Protocol (RTMP) over ethernet or a shared mobile internet connection over USB‑C.

Recording
Direct Recording Video and Audio
USB-C 3.1 Gen 1 expansion port can record directly to external media.

Video Recording
8 x SDI ISO inputs as H.264 .mp4 files at up to 70Mb/s quality at the ATEM video standard with AAC audio.

1 x Program out as H.264 .mp4 file at the Streaming quality setting and at the ATEM video standard with AAC audio.

Audio Recording
10 x 2 channel audio inputs recorded as separate 24‑bit 48KHz .wav files. Including 2 x analog 2 channel audio inputs and 8 x SDI 2 channel embedded audio inputs.

Switching
Program switching recorded as a DaVinci Resolve project .drp file.

Media Format
Supports media formatted ExFAT (Windows/Mac) or HFS+ (Mac) file system.

Multi View Monitoring
Multi View Monitoring
Configurable to 16, 13, 10, 7 or 4 up views including Program, Preview, 8 SDI inputs, SuperSource, Clean Feed, Media Player, Streaming Status, Recording Status and Audio Meters.

Multi View Video Standard
HD

Media Player
Media Players
2

Channels
Fill and key for each Media Player.

Media Pool Still Image Capacity
20 with fill and key.
