Total Video Inputs: 9
Total Outputs: 4
Total Aux Output: 4

SDI Rates: 1.5G, 3G

HDMI Video Inputs: 8 x HDMI type A, 10-bit HD switchable.
2 channel embedded audio.

HDMI Video Outputs: 3
HDMI Program Outputs: 3

Total Audio Inputs:
2 x XLR Combo with phantom power.
1 x BNC 32 Ch MADI digital audio.

Total Audio Outputs:
1 x 6.35mm headphone jack

Timecode Connection: None
Reference Input: None

Video Input Re-Sync On all 8 HDMI inputs and remote sources
Frame Rate and Format Converters On all 8 HDMI inputs and remote sources

Webcam Output: 2 x USB-C supporting 720p or 1080p at PGM frame rate.
Total Multi Views: 1 x HDMI, 1 x Webcam

Control Panel Connection
Ethernet. Direct connection between panel and chassis, or via network.

Internal Timecode Generator: Yes
Tally Output: On Blackmagic HDMI and remote cameras.

Ethernet
1 x 1G Ethernet for simple streaming, control panels and internet connection,
1 x 10G Ethernet connection for recording.

Computer Interface
2 x USB Type-C 3.1 Gen 1 for external drive recording, webcam out, software control, software updates and panel connection.
1 x Thunderbolt for fill key video out, video input, ethernet to storage, and power
