JVC DT-U31E (DTU31E) 31"" HDR UHD videomonitori 12G-SDI liitännällä ja quad 3G HD-SDI ja HDMI 2.0. 10bit IPS paneeli 3840 X 2160.

Uutuuspromotarjous

Lisätietoa

31 inch UHD 4K Professional Monitor. The DT-U Series monitors support both 12G-SDI or quad 3G-HD-SDI input, along with HDMI 2.0, with HDCP 2.2 for 4K input support.

HDR functions, including Hybrid Log Gamma (HLG) and PQ-3 formats. DT-U31 supports HLG-HDR and PQ-HDR and has the colour spaces DCI-P3 (100%) and ITU-R BT.2020 (84%).

Also supported is a range of camera logLUTs, including
S-Log, C-Log and JVC's J-Log.

Colour gamut support includes BT709 and BT2020, with automatic calibration possible via using an optional USB sensor which is connected directly to the monitor.

Waveform monitor and vectorscope, together with 16-channel audio metering.

DT-U models feature an expansion slot, for which a number of options are planned, including a fibre to SFP adapter.

Thanks to their high resolution and four separate HD-SDI inputs, they can also be used as quad-split displays, ideal for broadcast monitoring applications.

Properties:
The DT-U31 is a 31.5"" 4K UHD studio monitor with backlit LED. It has multiple 12G-SDI, 3G-SDI and HDMI connectors, allowing the monitor to display native 4K material at up to 60 frames per second. The DT-U31 supports HLG-HDR and PQ-HDR and has the colour spaces DCI-P3 (100%) and ITU-R BT.2020 (84%).

Native 4K monitor with backlit LED
Multiple 12G-SDI and HDMI ports
Support for HLG-HDR and PQ-HDR
Built-in 3D LUT auto calibration
Remote control via web browser possible
Technical Specifications:
Display: 31.5"" with backlit LED
Active Area: 698.4 x 392.9 mm
Resolution: 3,840 x 2,160
Color Space: DCI-P3 (100 %), ITU-R BT.2020 (84 %)
Color Depth: 10-bit, 1.073 G
Brightness: 300 cd / m2
Contrast: 3,000:1
Viewing Angle: 178° (H) / 178° (V)

Data Links:
Input

1x 12G-SDI via BNC
3x 3G-SDI via BNC
1x HDMI 2.0 via HDMI-A
1x SFP / IP via SFP module (optional)
1x Audio L/R via RCA
1x UMD via RS-485
1x GPI via RS-485
1x Ethernet via RJ-45
1x USB via USB-A

Output
1x 12G-SDI via BNC
1x HDMI 2.0 via HDMI-A
1x Headphones via 3.5 mm mini jack
2x Speaker, integrated
1x UMD via RS-485
General Product Information:
Dimensions (W x H x D): 748 x 485 x 91 mm
Weight: 11.95 kg
Operating Temperature: 0° to +40° C (10 - 90 % rel. air humidity)
Storage Temperature: -15° to +60° C (10 - 90 % rel. air humidity)
Operating Voltage: 100 - 240 V AC, 50 / 60 Hz / 12 - 17 V DC
Power Consumption: max. 75 W

Avecom on virallinen JVC ammattivideotuotteiden jakelija Suomessa
