Power is supplied by the USB-C connection to the host computer reducing clutter and eliminating the need for an external power supply. The rugged and compact design makes for easy portability and mobility.

The VAC-23SHUC's simple plug-and-play design uses UVC protocol to enable itself as a Camera Device. UVC protocol allows the host computer to set the parameters for the USB stream such as resolution, frame rate and aspect ratio.

3G/HDSDI input with active loop-through output supports formats up to 1080p50/60
USB 3.0 output is YUY2 format (equivalent to SDI 4:2:2 sampling). USB 2.0 mode is MP4
HDMI 2.0 input with active loop-through output supports formats up to 4096 x 2160 @ 30fps
USB output audio sampling rate is 48 KHz
Audio insert capability via 3.5mm stereo jack.
Insert into HDMI requires existing audio track be present
All power derived from USB port
10 Bit input sampling for improved image processing.
Plug-and-Play operation. No special drivers required
Compatible with popular applications including Zoom, Skype, OBS Studio, and many more

HDMI Color Sampling Formats supported:
1080p/720p: YCbCr 4:4:4 8/10/12bits, YCbCr 4:2:2 8bits and RGB 8/10/12bits 2160p: YCbCr 4:4:4 8bits, YCbCr 4:2:0 8/10/12bits, RGB 8bits

3GSDI Color Sampling Formats supported: YCbCr 4:2:2 10bits
