Video In
NDI®2,3, SRT, SDI, RTMP, RTSP
Video Out
NDI®, SDI
IP I/O
Up to 8x
SDI I/O
Up to 8x via HD-BNC
4K UHD I/O SDI I/O
Up to 2x via 12G-SDI, 6G-SDI, or quad-link 3G-SDI
Media Playback Channels
Up to 8x
Recording Channels
Up to 8x SDI Inputs Only
Supported Video Formats
2160p: 59.94, 50, 29.97, 25, 24, 23.976
1080p: 59.94, 50, 29.97, 25, 24, 23.976
1080i: 59.94, 50
720p: 59.94, 29.97, 25, 24, 23.976
576i: 50
480i: 59.94
1080p: 60, 59.94, 50
1080p/PsF: 30, 29.97, 25, 24, 23.98
1080i: 30, 29.97, 25
720p: 60, 59.94, 50
576i: 25
480i: 29.97
Supported Media Formats
Video: AVI, DV, DVCPro, DVCProHD, FLV, F4V, H.263, H.264, MOV, MKV, MJPEG, MPEG, MP4, WMV, WebM, and more
Image: PSD, PNG, TGA, BMP, JPEG, JPEG-XR, JPEG2000, EXR, RAW, TIF, WebP, and more
Audio: AIFF, MP3, WAV, and more
Audio I/O
Up to 8x SDI embedded
Audio Networking
Native support for network audio input and output via NDI®
Embedded SDI audio supported for all NDI® input and output video signals
Support1 for Dante™, AES67, and ASIO protocols via compatible audio drivers
Timecode
LTC Input and VITC Output
Signal Monitoring
Integrated waveform and vectorscope, full field rate with digital calibration, color preview and support for ITU-R Rec. 709
A/V Standards
12G-SDI (ST 2082-10)
6G-SDI (ST 2081-10)
3G-SDI Level A (ST 425-1 Level A Mapping),
Quad Link 3G-SDI (ST 425-5),
HD-SDI (ST 292),
SD-SDI (ST 259)
Video Processing
Floating Point, YCbCr +A 4:4:4:4
Audio Processing
Floating Point, 96 kHz
Genlock
Reference input supporting SD (Bi-level), HD (Tri-level), or network (NDI) supported
Multiviewer
1x USB Type C
NIC
1 x 10 Gigabit NIC (10GBASE-T over RJ45)
1 x 1 Gigabit NIC (RJ45)
System Physical
H 1.88in (4.28cm) x W18.97in (48.2cm) x D22.73in (57.75cm) / 23.19in (58.91cm) with Bezel - Racking Kit Included
27.38lb / 12.42kg
