Video Input
32 x simultaneous external video inputs, supporting any combination of compatible sources in resolutions up to UHD at frame rates up to 60fps (2160p 59.94)

Network Video Input32 x IP inputs via NDI®, resolution-independent, with support for key and fill

Video OutputConfigurable for up to 8 independent HD or 2 UHD video mix outputs, with simultaneous delivery via IP and SDI
Network Video Output48 x IP outputs via NDI® (HD and SD sessions only)
8 x video mix outputs in resolutions up to 1080p at frame rates up to 60fps (1080p 59.94) or 2 x UHD video mix outputs at up to 60 frames per second (2160p 59.94)
8 x direct IP source outputs via NDI® translation of local SDI inputs or 2 x upconverted UHD outputs at up to 60 frames per second (2160p 59.94)
4 x direct IP source outputs via NDI® translation of media players, with support for embedded alpha channel
15 x direct IP source outputs via NDI® translation of media buffers, with support for embedded alpha channel
3 x Multiviewer outputs (if 3 monitors are connected).
4K support on 2x Multiviewer outputs while the 3rd outputs in HD
1 x User Interface with dedicated multiviewer
1 x teleprompter output (LiveStory™ Creator)
8 x selectable IP outputs via internal NDI® matrix router

Media5 x media players
4 x DDR
1 x Sound
15 x media buffers
10 x animation buffers with GIF support
5 x graphic buffers
Keyers
Integrated LiveMatte™ chroma and luma keying technology on all source channels and M/E buses

32 x input keyers
4 x media player keyers
8 x M/E keyers
1 x PREVIZ keyer
15 x buffer keyers
COMPs
Integrated video composition engine on the switcher and each M/E bus to create, store, and apply layer configurations and DVE-style motion sequences

16 x configurable COMP presets per bus
Virtual SetsIntegrated LiveSet™ technology with 30+ live virtual sets and box effects included
DataLinkIntegrated DataLink™ technology enabling real-time, automated data input from internal and external sources, including webpages, spreadsheets, scoreboards, databases, RSS feeds, watch files, XML, CSV, ASCII and more

RecordingRecording Capabilities (maximum recording capabilities depend on storage performance, network bandwidth and video format)
8 x configurable MIX output channels for HD or 2 x for UHD
8 x physical SDI inputs
4 x DDR's
3 x streaming encoders
32 x configurable inputs
Support for growing file playback from DDR's
Instant Replay capability on each input
Ability to record alpha channel
Storage4TB Media Storage (4 x 1 TB SSD in RAID 0)
Quantity varies by format, resolution and file specification
Supports recording to external storage via 7 USB 3.2 type A, and 1 USB 3.2 type C, 1 USB 2.0 2(Gen2, Type A)
Supports shared storage integration and third-party partner solutions
